Wave Living Hinge is a public wave living hinge variation with 6 customized values saved for quick export and remixing.
Saved Design
Wave Living Hinge
Wave Living Hinge saved on May 5, 2026.
Wave Living HingeBendingPublic DesignState ID 8VoHQa
Design Summary
6 custom values
Created
May 5, 2026
Design Snapshot
Main values in plain language
Wave Living Hinge configured with width 220 mm, height 50 mm, plus additional tuned values.
Wave Living HingeBendingLaser CutSVGDXFPublic DesignCustom ValuesColumn SpacingHeightHorizontal MarginVertical Margin
Measurement Summary
220 mm
50 mm
Custom Values
Parameters changed from the generator defaults
These are the saved values that make this design different from the default Wave Living Hinge setup.
Column Spacing
3.75
Height
50
Horizontal Margin
0
Vertical Margin
0
Wave Amplitude
2.4
Width
220
Recommended Uses
Projects this design suits well
These suggestions come from the base generator category and are useful starting points when deciding where to apply this saved variation.
Laser cutting projects
CNC-ready vector design
Decorative panel layouts
Custom fabrication files
Export Guidance
When to use SVG vs DXF
Both exports are generated from the same saved values, so the best choice depends on what tool you plan to use next.
SVG
Best for vector editing and quick laser workflows
DXF
Best for CAD-oriented fabrication pipelines
PNG / PDF
Best for review, sharing, and client approval
